انکدر چرخشی دیجیتال مدل ENC-68-M01AI

Supply Voltage

6-35V

Power Consumption

Max. 50 mA

Applicable Functions

Incremental ABZ(RS422),  Absolute SSI (RS422)

Incremental position resolution

1-1024 PPR factory programmable

Absolute position Resolution

Up to 10 bits

Dynamic Angle Error

± 0.18 degree

Accuracy

Typ. ± 0.5 deg

Power-on time

10 ms

Output Signals

Differential ABZ, SSI (RS422)

EMC compliance

EN IEC 61326

Operating Temperature

-40 to 105 degree C

Protection class

IP 67 (IEC60529)

Shock

<2000 m/s2 (IEC60068-2-27)

Vibration

<300 m/s2 (IEC 60068-2-6)

Cover material

Aluminum Alloy 7075

Outer diameter

68 mm

Mounting Holes

3 x M3 & 3 x M4

Shaft

Stainless steel ϕ10 mm

weight

450 grams
